HTG-A Full Height ADA Access Gate
Our HTG-A full height access gate provides the same floor to ceiling level of security as our full height turnstiles while simultaneously providing an ADA compliant clear opening. This model features a spacious 36” opening to provide ample entry space for wheelchairs, deliveries, toolboxes, and more. The HTG-A is a great choice for entry and exit control via card swipe, push button, key turn, other means of controlled access. Our HTG-A works great as a standalone access control solution, but it truly shines when paired with one of our SecureTurn series full height turnstiles to provide a comprehensive access control solution.
All Hayward Turnstiles full height ADA gates are designed for handicap access, but they are also often used as an alternate entrance alongside turnstiles for those entering with push carts, bulky deliveries, strollers, tools, and any other object that would not easily fit through a regular full height turnstile.
Starting Price: $4,500
Applications
Our HTG-A is the perfect solution for anyone looking to harness the floor to ceiling security of a full height turnstile without sacrificing handicap accessibility. Our HTG-A isn’t just for handicap access, though. It is a great solution for entrances that frequently require larger objects to pass through like tool boxes, luggage, hand trucks, and more that wouldn’t fit easily through the entryway of a conventional full height turnstile. Simply install an HTG-A next to your full height turnstile to provide an alternate entrance for handicap access and/or bulky items. With an included key lock and electric strike lock that integrates with nearly any credential device, this gate is the perfect full height entrance control solution for anyone looking to control access into and out of their facility by way of key, card reader, proximity scanner, push button, or other credential devices.
Specifications
Finish: Galvanized, Powder Coat, Powder Coat over Galvanized
Door Width: 36"
Total Width: 41"
Full Panic Bar: Not included, check out our HTG-M gate for panic bar gate needs.
Self-Closing Hinge: Included
Manual Key: Included
Electronic Entry/Exit: Included
Electronic Push Button: Optional
Reader Mount Plates: Optional
Details
Materials and finishes in your choice of:
- Available in your choice of galvanized, powder coated, or powder coat over galvanized finish to match your entryway or pair perfectly with one of our full height turnstiles.
Design and Construction:
- Designed as an ADA-compliant solution for perimeter security
- ADA-compliant passage width
- Fully welded exterior components
- Built from heavy-gauge materials that meet ASTM standards
- Vertical steel bars keep unauthorized entrants out
- Minimally exposed, tamper-proof hardware
Gate Operation:
- Gate automatically closes with included self closing hinge
- Field reversible electronic strike lock (24VDC) included
- Strike lock can be used mechanically with a key or electronically when integrated with virtually any access control software via a momentary dry contact
- Gate can be locked and unlocked using a key
- Monitored latch included to detect lock/unlock status and open/close status
Electrical Specifications:
UL Approved Electronic Strike: Input Voltage: 24VDC Input Current: 170 mA
Warranty:
Units are warranted against defects in materials and workmanship for one year.
HT431T SecureTurn Full Height Tandem Turnstile Dimensions
Frequently Asked Questions
Need Installation?
Hayward Turnstiles has a nationwide network of partner installers. Our team is happy to coordinate installation with one (or multiple) of our certified installers who will handle the purchasing, installation, and integration of turnstiles and gates for you.
One point of contact. One comprehensive warranty. One goal: complete project satisfaction.
What Are the Benefits of the HTG-M?
- Matches SecureTurn full-height turnstiles
- ADA-compliant lane width
- Included electric strike that integrates with nearly any access control reader, push button, or RFID scanner
- Included key lock for easy locking and unlocking via key turn when a reader device is not required
